BUY HS120 Fin Stabilizers – SE Stabilis Electra System (California)
California’s Pacific swell, afternoon wind chop, and high-traffic waterways can make even large yachts feel busy at speed. The HS120 Fin Stabilizers (SE Stabilis Electra System) are built for bigger planing yachts that need strong stabilization authority, fast response, and dependable marine-grade construction—helping deliver a smoother, more controlled ride along the California coast.
The HS System is an evolution of the SE Stabilis Electra platform, engineered to suit virtually all hull shapes and optimized for planing yachts. Upgrades focus on improved fin efficiency for reduced resistance, electronics designed for faster stabilization performance, and the ability to control integrated onboard systems—such as steering and intruder functions—alongside fin operation.
Built for Large Planing Yachts and Demanding Sea States
HS120 is designed to deliver high stabilization capability while maintaining efficient hydrodynamics. In California conditions, that translates to:
- Improved comfort and reduced fatigue on longer coastal runs
- Better control when pushing through swell and wind-driven chop
- Reduced roll motion for guests and crew at cruising speeds
- A refined fin profile aimed at lowering drag while maintaining authority
Key System Advantages
- Evolution of SE Stabilis Electra, optimized for planing yachts
- Efficient fin profile designed to reduce resistance
- Upgraded electronics for faster response and performance
- Ability to manage integrated systems (steering/intruders) in addition to fin control
- Heavy-duty mechanical design for long-term durability in marine environments
Engineering & Construction Details
HS120 is built around robust, service-minded components designed to withstand saltwater exposure and continuous use:
- Fin connection: Precision machined oversized self-locking taper
- Shaft: 120 mm duplex stainless steel
- Actuator housing: High-strength ductile iron
- Bearings: Heavy-duty tapered roller bearings (upper and lower)
- Lower seal: Two double-lip seals for maximum seawater protection, accessible in a 316 stainless steel retainer
- Upper seal: Double-lip, spring-loaded seal for grease retention and protection against external contaminants
- Lubrication: Pre-packed water-resistant grease for lifetime maintenance-free service; reduction gearbox lubricated with mineral oil
- Fit & finish: Painted RAL 9016 and polished
HS120 Specifications
| Specification | HS120 |
|---|---|
| Model | HS120 |
| Actuator Weight (incl. electric motor) | 362 kg – 394 kg |
| Motor Type | Brushless with electromagnetic brake |
| Applicable Motor Rating | 9.0 kW or 11.0 kW |
| Standard Fin Size Options | 2.35 m² / 2.50 m² |
| Maximum Fin Rotational Speed | > 80 deg/s |
| Power Supply | 400V AC 3-phase or 200V AC 3-phase |
| Frequency | 50 Hz or 60 Hz |
| Maximum Absorption Underway* | — |
| Maximum Absorption At Anchor* | — |
*Power absorption values may vary by installation and operating conditions.
Why HS120 Makes Sense in California
For large planing yachts operating along the California coast, HS120 is designed to deliver powerful roll reduction with fast response and an efficiency-minded fin profile. With upgraded electronics, heavy-duty construction, and integration-ready control capability, it’s a stabilization system built for owners who want smoother cruising, greater confidence, and a more comfortable onboard experience in the sea states California is known for.
