INTERCEPTA X80 Trim Tabs in California
California cruising can be a mix of long-period Pacific swell, afternoon wind chop, and wake-heavy harbors—conditions that can make even larger yachts feel unsettled. INTERCEPTA X80 Trim Tabs are designed to actively manage running attitude and comfort by delivering precise, fast trim control. As part of MC²’s latest plug-and-play active intruder X Series, X80 helps improve stability, handling, and efficiency for yachts that spend real time on the California coast.
INTERCEPTA trim tabs can actively reduce both roll and pitch up to 50%, helping deliver a smoother, more stable ride in challenging sea states and everyday coastal conditions.
What Makes INTERCEPTA X Series Different
The INTERCEPTA X Series is engineered for protected installation and flexibility, combining ready-to-use models with customization options:
- Motor placed inside the hull for protection and a cleaner exterior installation
- Four standard, ready-to-use models plus tailor-made sizing via a dedicated customization service
- Series crafted through mechanical processing for precision and consistent fit
- Motor position adjustable on request for installation versatility
- Designed to support active stabilization, easier turns, and smoother control
- Built to help reduce fuel consumption by optimizing trim and running efficiency
INTERCEPTA is available in two ranges:
- INTERCEPTA IN Series: integrated electric actuator for simpler installation
- INTERCEPTA X Series: customizable sizing with motor mounted inside the hull
Why X80 Is a Smart Fit for California Yachts
For 50–80 ft yachts, comfort and control often come down to how well the vessel manages pitch in chop and roll in quartering seas. X80 is designed to help deliver:
- A calmer ride through wind chop and cross wakes
- Improved running angle for comfort, visibility, and confidence
- Easier turning behavior and better overall handling
- Reduced fatigue during longer coastal runs and island crossings
Integration Compatibility
- Seacentric System compatible
- Xenta System compatible
Specifications
| Specification | X80 |
|---|---|
| Model | X80 |
| Boat/Yacht Length* | 15–24 m / 50–80 ft |
| Blade Length (A) | 800 mm / 31.49 in |
| Intercepta Dimensions (W × D × H) | 800 × 80.5 × 217 mm / 31.49 × 3.16 × 8.54 in |
| Servo Unit Dimensions (W × D × H) | 330 × 235 × 184.5 mm / 12.99 × 9.25 × 7.26 in |
| Control Unit Dimensions (W × D × H) | 267 × 51 × 168 mm / 12.51 × 2 × 6.61 in |
| Weight | 23.5 kg / 51.8 lb |
| Operating Temperature | 0 to +40°C / 32°F to +104°F |
| Stroke | 50 mm (80 mm available on request) / 1.96 in (3.15 in on request) |
| Power Supply | 10–32 Vdc |
| Blade Speed | Up to 40 mm/s / up to 1.57 in/s |
| Battery Type | Lead, AGM, Gel, Lithium |
| Maximum Power Consumption | 0.2 kW |
| Auto Cleaning | Yes (timing customizable: min 1/day to max 1/month) |
| Transom Thickness | 20–75 mm / 0.78–2.95 in |
| Approval | CE |
| Maintenance | Annual (lifting the boat). Mandatory inspection of blade sliding for marine organism intrusion/antifouling. |
Auto Cleaning for Saltwater Operation
Marine growth is a reality for California boats. X80 includes auto-cleaning with customizable timing (from daily to monthly) to help keep blade movement clear and consistent, supporting reliable performance over time.
A More Comfortable, More Controlled Cruise
INTERCEPTA X80 is built for owners who want a smoother ride and sharper control without complicated systems. With fast blade actuation, inside-the-hull motor placement, active roll/pitch reduction capability, and modern system compatibility, X80 is a strong trim-tab solution for 50–80 ft yachts cruising California waters.
